SolarKing SK-33 Solar Regulator

Home / Solar Regulators

Heavy duty SolarKing Solar 30AMP solar regulator also known as solar charge controller. The unit has a large heat sink to dissipate heat and large wire terminal connections to accept large gauge cables. LCD display built in and the unit has a load timer built in for running lighting once daylight has run out for the day.

Solar regulators are used to connect your solar panels to batteries so the battery is charged at the correct power rates.

  • 30 Amp Maximum Current
  • 12/24VDC Auto Select
  • USB Charging Socket
  • Adjustable Load Timer Output
  • Large Heat Sink
  • Charge Status Indicator
  • Under and Over Voltage Indicators
  • Load on/off Selectable
  • LCD Display
  • Large Terminals for large cables
  • Reverse Polarity Protection
  • PWM 3 Stage Charging
  • 2 Hour Boost Charge when under voltage
  • Over Current Protection
  • Reverse Polarity Protection
  • Dimensions
    199x95x43mm
  • Mounting holes
    189x70mm
  • Weight
    410grams
  • Terminal Size
    16mm2
  • Enclosure Rating:
    IP32
  • Temperature Range
    -20°C~+55°C
  • Voltage Range
    12/24V Auto Selectable
  • Standby Current Drain
    10mA
  • Maximum Current
    30AMP
  • Maximum Input Voltage
    55Vs
  • Overload Protection
    30sec restart
  • 1x Solar Regulator
  • 1x Instructions
  • 1x Gift Box
